| D-1 PVDF Lithium Ion Battery Binders |
|
D-1 PVDF are widely used as binders in lithium ion battery industry, and as battery separators in lithium-ion polymer technology.
D-1 PVDF is high dielectric constant, which shows high viscosity and bonding properties in some solvent, easy to form film. D-1 PVDF powder as raw materils, the lithium ion battery membrane have good chemical stability, temperature stability, excellent mechanical strength and processability.
D-1 PVDF technical data sheet |
Properties |
Typical Values |
Standard |
Appearance |
White solid powder |
|
Odor |
None |
|
Purity |
99.5% |
|
Standard specific gravity |
1.74-1.77 |
ASTM D792,at 23/23℃ |
Melting point |
160-168℃ |
ASTM D3418 |
Solubility |
Solution is clear and transparent |
30℃,1hr |
no impurity and insoluble matter |
1g/10ml NMP |
Rotary Viscosity |
3000-6000mPa·S |
0.1g/ml NMP,30℃ |
Water absorption |
0.1% |
Karl Fischer |
|
Safety instruction
D-1 PVDF is stable under 310deg.C, when it is stored at 310-320deg.C for a long time, trace toxic hydrogen fluoride(HF) and fluorocarbon organic chemicals(FC) begin to release, when the temperatures more than 370deg.C, HF and FC release speed up. So, a temperature below 310deg.C is suggested for processing and using D-1 PVDF.
Furthermore, although D-1 pvdf have good flame retardancy, in case of fire, HF and FC will also be released.
Packing
20kg/carton |
|
